wedi building panels XL and XXL

wedi building panels XL and XXL

„Stand-alone, robust wall solution with
only one single wedi building panel.“

Product information

wedi building panels have a blue core made from CFC-free extruded polystyrene rigid foam. This makes the wedi building panel an ideal basis for any type of plaster and tile. wedi building panels can be applied to practically any substrate, they are waterproof, insulating, versatile, light and robust.

These large building panels stand out because of their distinctive width, of up to 4' (1.20 m). This means that the XL and XXL building panels are easy assembly with all the benefits of the classic wedi building panel such as being light and easy to handle, despite their size. Simple to assemble and big in quality.

  • The blue XPS core is 100% waterproof and remains fully functional even after possible damage.
  • The cemented surface is a good adhesive under-surface. The fibre fabric also absorbs tensile forces.
  • All building panel systems have great heat insulation properties,

All advantages at a single glance

Product video: wedi building panels XL and XXL

Technical data of building panel XL & XXL


wedi Building Panel Material Composition XPS/ Extruded Polystyrene Foam Core covered with f
Surface Burning Characteristics; ASTM E84-04 and U Passes
Tensile Strength ( Thinset Mortar to wedi Coating 65 PSI
Shear Strength ( Thinset Mortar to wedi Coating to 54 PSI
Flexural Strength; ASTM C947 627 PSI
Linear Variation; ASTM 1037-39 ( AC159) Passes / less than 0.074%
wedi Fastener Pull Through Strength; ASTM C 473 Wet 131.8 PSI/ Dry 196.2 PSI
Accelerated Aging Test; AC71-25 Cycles No Disintegration
Waterproofness; ASTM D4068 and within ANSI 118.10- Passes
Waterproofness of Assembled System; IAPMO PS 106-2 Passes
Capillarity 0
Temperature Exposure Limits -58°F to + 175°F
R- Value; ASTM C518 4.3hr ft. 2 F/Btu/in ( R – value for 1 inch of wed
Robinson Floor Test; ASTM C627
*with 8” x 8”
Heavy Duty Commercial Use, Passes
Fungus & Bacteria Resistance No Growth , Passes

Building & Plumbing Code Compliance

Compliant


Compliant
2010 and 2005 National Plumbing Code of Canada Compliant


Compliant

ANSI 118.10-2008 Load – Bearing Bonded, Waterproof Compliant



Compliant
New York City Approval OTCR

City of L.A
Approved

Approved; Report No M-100017 i
Worldwide Approvals Quality Management & Control ISO 9001-2008

Approved, File 20130265

Product sizes

Order no. Designation Length x width x thickness
010000912 wedi building panel XL 1/2" (12.5 mm) 3' x 8' x 1/2" (900 x 2500 x 12.5 mm)
010001612 wedi building panel XXL 1/2" (12.5 mm) 4' x 8' x 1/2" (1200 x 2600 x 12.5 mm)
01000250 wedi building panel XXL 2" (50 mm) 4' x 8' x 2" (1200 x 2500 x 50 mm)

wedi building panels XL and XXL - Timecode 2:52

Area of application wedi building panels XL & XXL

  • XL and XXL building panels stand out because of their exceptional width up to 4' (1.20m). The XL and XXL building panels bring together all the benefits of classic wedi building panels and are also particularly light and easy to handle, despite their size. Simple to assemble and big in quality.
